Working Principle
|
||
|---|---|---|
|
Working Principle
|
Control Type |
Manual 3-way valve or Optional Electric Solenoid Valve |
| Working Mechanism |
Filling and emptying of the diaphragm with the system's own pressure |
|
| Solenoid Modes |
Normally Open (NO) or Normally Closed (NC) (Positive/Negative control) |
|
| Speed Adjustment |
Closing speed can be adjusted with a one-way flow restrictor (During ordering) |
|
|
Structural Features
|
||
|
Structural Features
|
Basic Parts |
Body, Cover and Diaphragm |
| Diaphragm Design |
"Springless" design (Distributes pressure evenly, prevents deformation, long-lasting) |
|
| Closing Characteristic |
Gradual closing (Prevents water hammer) |
|
| Maintenance |
Contains minimum moving parts, practically maintenance-free |
|
| Performance |
Precise regulation at low flow rates, full opening at low pressure (Low head loss) |
|
|
Technical Data
|
||
|
Technical Data
|
Diameter Range |
DN50 - DN400 |
| Operating Pressure |
PN10 - PN16 |
|
| Temperature Range |
Between 2°C and 40°C |
|
| Main Valve Material |
EN-GJS-400-15 |
|
| Standards |
DIN / ANSI / BS compliant |
|
|
Connections and Indicators
|
||
|
Connections and Indicators
|
Flanges |
DIN 1092-2 (Can be changed upon request) |
| Pressure Indicator |
EN 837-1; Accuracy class 1.6 |
|
