Assembly / Disassembly Parts
Dismantling joints are equipments that facilitate the installation and removal of valves by compensating for changing assembly dimensions.
Why Choose ATLAS Dismantling Joints?
ATLAS installation and dismantling joints make it easier to fit flanged valves into pipelines and remove them for maintenance. An adjustable installation length helps accommodate connection spacing within the permitted range, allowing service access to be planned more effectively.
An EN-GJS-400 ductile iron body, flanged connections and thermoplastic or electrostatic coating options provide a mechanical solution for different installations. The listed DN80–DN2200 range and PN10/PN16 pressure options are evaluated together with the dimensions and flange standard of the quoted model.
Installation lengths and flange dimensions in the table allow joints to be matched to project valves in advance. Correct selection helps reduce unnecessary pipeline alterations during servicing. Maintenance must be undertaken with the line depressurised and safely isolated.
Key benefits
- Adjustable connection spacing for valve installation and removal.
- Ductile iron body and flanged connections.
- Project-specific diameter, pressure rating and coating selection.
General Description | ||
|---|---|---|
General Description | Product Description | Equipment that facilitates the installation and removal of valves by compensating for varying assembly dimensions |
| Body Material | Ductile Iron EN-GJS-400 | |
| Paint / Coating | Thermoplastic, Electrostatic | |
| Connection Type | Flanged | |
Operating Conditions | ||
Operating Conditions | Nominal Diameter Range | DN80 - DN2200 |
| Nominal Pressure | PN10 - PN16 | |
| Temperature Range | -10°C to +80°C (Depending on material structure) | |
